License Plate Recognition Parking System

Touchless Parking Pay Station with 19.1" Auto Payment Display for Parking System

Name: Touchless Parking Pay Station with 19.1" Auto Payment Display for Parking System
Brand: Shenzhen Realpark Co., Ltd.
SKU: RPL-POF-PS01
Price: 491.00 USD
Availability: InStock

Brand Name:	Realpark
Model Number:	RPL-POF-PS01
MOQ:	1 set
Price:	Welcome to contact us!
Delivery Time:	1-2 weeks
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE and ISO9001

Part Number:

RP-POF-PS01

Payment Method:

Bank Card, ATM, QR Code, Coin, Banknotes

Display:

19.1" Touch Screen Display

Installation:

Floor-standing

Wooden Package Size:

L58*W73*H180cm

Gross Weight:

180kgs

Part Name:

Auto Pay Machine

Products Type:

AutoPay Parking Station

Payment Methods:

Cash, Credit/debit Cards, Mobile Payments

Warranty:

1 Year

Packaging Details:

62*75*180cm/147kgs/set/Wooden

Supply Ability:

100sets/Month

Product Description

Touchless Parking Pay Station with 19.1" Auto Payment Display for Parking System

The Touchless Parking Pay Station features a 19.1-inch Auto Payment Display, designed to streamline the parking payment process. This innovative solution allows users to complete transactions quickly and safely, minimizing physical contact and enhancing the overall parking experience.

Touchless Parking Pay Station with 19.1" Auto Payment Display for Parking System 0

Auto Pay Station Configuration POF
No.	Module	Specifications	Technical Parameters
1	Main control module	Specify	Motherboard: 10 RS-232 ports, 8 USB ports, 2 1000M network ports, Display interface: 1VGA+1HDMI, integrated sound card, graphics card, network card, USB; CPU: Intel I5 4th generation; Memory: 4G, Hard disk: SSD 120G.
2	Host chassis + power supply	Specify	400W power supply
3	Display capacitive touch integrated screen	Specify	The screen size is 19 inches, the response time is 6ms, the brightness is 260 Nits, the contrast ratio is 700:1, and the viewing angle is 130 degrees horizontally and 110 degrees vertically.
4	Banknote circulation module	Specify	High capacity, high security bill validator Proven field reliability Easy maintenance with free firmware updates Lockable, removable cash drawer for up to 1000 notes Superior performance - auto-centering technology straightens notes before reading Accepts notes up to 85mm wide and standard industry barcode tickets Power supply:Required: 12V Standby: 400mA Running: 1.5A Peak: 3A Protocol: SSP IF003 ccTalk MDB Interface: USB RS232 Open Collector:Frame Options Standard Frame: Metal Frame Self-aligning Frame Various lighting options Cash drawer options: 500 notes 1000 notes Note sizes:Width: 60 - 85mm Length: 115 - 170mm MCBF: 200,000
5	POS three-in-one card reader	Specify	Reserved space for adding cover plate (model specified) Pax-IM30, please check the 2 bank card POS machine data sheets in the PDF file
6	Barcode scanning	Specify	Image sensor: 1280H800V Field of view: 43° horizontal, 50° diagonal, 28° vertical Read rate: 50ms Decodable symbols: 2D QR code, etc. 1D: UPC/EAN/CODE128/CODE32/CODE39/CODE93/UCC/UPCA, etc. Reading accuracy: 5 mil Reading distance: CODE 39 (12 mil): 20cm-55cm, UPC-A (16 mil): 10cm-60cm, QR code (payment code): 5cm-130cm Contrast: >25% Deflection angle: horizontal ±55°, vertical ±55°, rotation 360° Reading mode: trigger/sensing/continuous Communication interface: Standard: USB, optional: TTL/RS485/RS232 Dimensions: length, width, height (65mm, 64mm, 29mm) Weight: 36g Operating voltage: 4.75V-12.6V Rated power: 0.80W Operating current: 160mA Standby current: 90mA Reading material: screen, paper, metal, PVC film Indicator: two-color indicator
7	Intercom system	Specify	Intercom (to be confirmed later)
8	Printer module	Specify	Printing method: Line thermal printing Print density: 8 dots/mm Printing direction: Paper feed direction Printing speed: 150 mm/sec (max) Paper width: 79.5±0.5 mm Effective printing width: 72 mm Paper handling: Automatic paper cutting Line width: 3.75 mm
9	Coin circulation module	Specify	Five structural parts are reserved for sealing Mixed coin hopper and recycler Requirement: 24V Standby: 200mA Running: 3A Peak: 6.5A Protocol: SSP ccTalk Interface: USB option open collector Coin size: 18 - 28.5mm Thickness: 1.65 - 3.2mm Coin capacity: 1500 (€1) or 1300 (£1) or 800 (£2) Multiple denominations: up to 11 denominations Mixed coin capacity: 200 (€2) + 750 (€1) + 500 (50c) Payout speed: up to 12 coins per second MCBF: 200,000
10	Alarm module	Specify	Security warning system (access control device + control board + sensor + alarm)
11	LED light	Specify	One set of breathing lights, one set of blue lights (with control board)
12	Combined power supply module	Specify	Provide 12V, 24V (110V 50HZ) power for printers and other components
13	Sound effect system	Specify	One on each side, effective output 25W.
14	Cooling system	Specify	4 fans with dust screen
15	Tempered glass panel	Specify	Thickness: 3mm
16	Banknote and coin password safe	Specify	Factory settings: User password "1111", Administrator password "00000000". Unlock: Enter the password you set, the password length should be 4-10 digits (if not set, please use the factory password). Each digit entered will have a sound prompt to indicate validity. After entering the password, press the OK button
17	UPS power supply module	Specify	1000VA, USB interface, with program control
18	Complete machine cabinet (outdoor powder)	Specify	Hall-style structure, with hot steel plate on the outside. Thickness of the whole machine shell: 1.5-2.0mm Appearance: novel, beautiful, and noble; Material: hard and thick, not easy to deform; Internal structure: modular maintenance method, simple and convenient maintenance; wiring is standardized and neat. Contains safe. Universal key for cabinet. (Note outdoor powder)
19	Complete machine cabinet multi-point linkage lock	Mechanical multi-point lock	Multi-point lock for whole cabinet
20	Complete machine accessories	Circuit breakers, socket strips, wires, etc.
21	Communication method	TCP/IP Method

Touchless Parking Pay Station with 19.1" Auto Payment Display for Parking System 1

Touchless Parking Pay Station Features:

19.1-Inch High-Resolution Display: Provides a clear, interactive interface for users, ensuring easy navigation and payment processing.
Touchless Payment Options: Supports NFC payments, QR code scanning, and mobile wallet transactions for a seamless, contact-free experience.
User-Friendly Interface: Intuitive design guides users through the payment process step-by-step, reducing confusion and wait times.
Real-Time Transaction Processing: Instantly processes payments and updates parking availability, offering accurate information to both users and operators.
Built-In Printer: Issues receipts or parking tickets on demand, ensuring users have necessary documentation for their transactions.
Durable and Weather-Resistant: Designed for outdoor and indoor use, built to withstand various environmental conditions.
Remote Monitoring Capabilities: Operators can oversee system performance and transaction data from any location, enhancing management efficiency.
Comprehensive Reporting Tools: Provides detailed reports on payment history and usage patterns for informed decision-making.
Customizable Display: Allows for branding and personalized messages to enhance user engagement and facility identity.
Scalable Solution: Suitable for various parking environments, from small lots to large commercial facilities.

19.1" Auto Payment Display for Parking System Payment Station

Benefits:

Enhanced User Convenience: Touchless payment options increase user satisfaction by providing a quick and safe payment experience.
Operational Efficiency: Real-time processing and reporting tools enable effective resource management and operational oversight.
Increased Revenue Opportunities: By accommodating diverse payment methods, the station can attract more users and boost revenue.

Parking Ticket Payment Machine

Applications:

Public Parking Lots
Shopping Centers and Retail Establishments
Airports and Transit Stations
Event Venues and Stadiums
Corporate Campuses and Institutional Parking Areas

Touchless Parking Pay Station with 19.1" Auto Payment Display for Parking System 4

Car Plate Recognition System Automatic Pay Station FAQ

Q1: What is the main function of the Touchless Parking Pay Station?
A1: It allows users to make parking payments easily and safely through various contactless payment methods.

Q2: What payment methods are supported?
A2: The station supports NFC payments, QR code scanning, mobile wallets, and traditional card payments.

Q3: Is the user interface easy to navigate?
A3: Yes, the 19.1-inch display features an intuitive design that guides users through the payment process.

Q4: Can the pay station operate outdoors?
A4: Yes, it is built to withstand outdoor elements, making it suitable for various environments.

Q5: Does the station print receipts?
A5: Yes, it includes a built-in printer that issues receipts or parking tickets upon successful payment.

Q6: How does real-time transaction processing work?
A6: The system processes payments immediately, updating transaction records and parking availability in real time.

Q7: Can operators monitor the system remotely?
A7: Yes, operators can access performance data and transaction history from any location.

Q8: What reporting features are available?
A8: The station provides detailed reports on payment history, usage patterns, and other key metrics.

Q9: Is the display customizable?
A9: Yes, the interface can be tailored for branding and to include specific messages for users.

Q10: How can I acquire the Touchless Parking Pay Station?
A10: You can request a quote through our website or contact our sales team for customized solutions.

The Touchless Parking Pay Station with 19.1" Auto Payment Display is an advanced solution designed to enhance the parking payment experience by providing a fast, safe, and user-friendly interface for modern parking management.
