License Plate Recognition Parking System

Parking Infrared Fill Light DC12V Built In Or AC110V~230V Built Out

Name: Parking Infrared Fill Light DC12V Built In Or AC110V~230V Built Out
Brand: Shenzhen Realpark Co., Ltd.
SKU: RPL-IRLight
Price: 491.00 USD
Availability: InStock

Brand Name:	Realpark
Model Number:	RPL-IRLight
MOQ:	1 set
Price:	Welcome to contact us!
Delivery Time:	1-2 weeks
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE and ISO9001

Part Name::

Infrared Fill Light

Part Number::

RPL-IRLight

Output Voltage：:

DC12V Or AC110~230V

Color：:

Black

Support：:

LPR Parking Controller, Car Plate Recognition Camera

Light Distance：:

Customizable (Depending On The Wattage Of The Lamp)

Packaging Details:

25*18*12cm/1kg/1 Set/Box

Supply Ability:

10000sets/Month

Highlight:

Parking Infrared Fill Light

DC12V Infrared Fill Light

AC110V Ir Fill Light

Product Description

Parking Equipment Infrared Fill Light DC12V Built-In or AC110~230V Built-Out

Looking for reliable parking equipment with infrared fill light? We’ve got you covered! Our product comes with a built-in DC12V, or choose the option with built-out AC110~230V - offering flexibility to suit your needs. With this powerful and versatile fill light, you can enhance visibility and security in any parking environment. Don't miss out on this essential addition to your parking setup!

Accurate constant current drive power supply enables LED to play its better characteristics.

Parking Infrared Fill Light DC12V Built In Or AC110V~230V Built Out 0

Technical Specifications:
1. Working voltage: DC12V2A

2. Working mode: light control photosensitive switch control (optionally no light control).

3. Mounting bracket: Universal U-shaped bracket.

4. Environmental temperature:-40°C to + 55°C
5. Protection grade: IP65-66 6. Color: gray (white)
7. Panel: tempered glass

8. Protective cover: molded aluminum shell

Basic Product Parameters:

1. Infrared light: LED array light (850nm-940nm) Optional

2. Laser (850nm-940nm)
3. Beam angle: 90°- 9° (optional) 4.8°- 30° (optional)

Product parameter	Angle (°)	Corresponding lens
16PCS (6lasers + 10 lattice) 16PCS (lattice) 16PCS (4 lasers +12 lattice) 850nm (940nm) Power: 32-48W Shell size: 16010055mm	90	4mm
	60	6mm
	45	8mm
	30	12mm
	15	16mm

The effect picture after installing the fill light is as follows:

Parking Infrared Fill Light DC12V Built In Or AC110V~230V Built Out 1

Parking Infrared Fill Light DC12V Built In Or AC110V~230V Built Out 2
